Description
Performance| SG 430 Rev. 2
Firewall throughput: 28 Gbps
VPN throughput: 4 Gbps
IPS throughput: 7 Gbps
Antivirus throughput (proxy): 2 Gbps
Concurrent connections: 8,000,000
New connections/sec: 130,000
Maximum licensed users: unrestricted
Physical interfaces
Storage (local quarantine/logs): integrated SSD
Ethernet interfaces (fixed): 8 GbE copper (incl. 2 bypass pairs)
2 10 GbE SFP+
No. of FleXi Port slots: 2
FleXi Port modules (optional): 8 port GbE copper
8 port GbE SFP*
2 port 10 GbE SFP+*
4 port 10 GbE SFP+*
2 port 40 GbE QSFP+*
4 port GbE PoE
8 port GbE PoE
I/O ports (rear): 2 x USB 3.0 (front)
1 x Micro USB (front)
1 x USB 3.0 (rear)
1 x COM (RJ45) (front)
1 x IPMI (front)
1 x HDMI (rear)
Display: Multi-function LCD module
Power supply: Internal auto-ranging
90-264VAC, 50-60 Hz
Redundant PSU optional (external)
Physical specifications
Mounting: 1U rackmount (sliding rails incl.)
Dimensions
Width x Depth x Height:438 x 483 x 44mm
17.24 x 19 x 1.75 inches
Weight: 7.6 kg / 16.76 lbs (unpacked)
12.7 kg / 28 lbs (packed)
Environment
Power consumption: SG 430: 28W, 96 BTU/hr (idle)
79W, 270 BTU/hr (full load)
SG 450: 31W, 107 BTU/hr (idle)
83W, 283 BTU/hr (full load)
Operating temperature: 0-40°C (operating)
-20 to + 80°C (storage)
Humidity: 10%-90%, non-condensing
Product Certifications
Certifications: CB, UL, CE, FCC Class A, ISED, VCCI, RCM, CCC, KC, BIS
